CREATBOT DM SERIES

CREATBOT

$2,899.00

NUMBER OF EXTRUDERS
Quantity

Machine Parameters

  • Product name: CreatBot DM Series
  • Build size (LDH):
  • 250*250*300mm DM
  • Number of nozzles: single / double
  • Nozzle diameter: 0.3, 0.4, 0.5, 0.8, 1.0mm
  • Minimum thickness: 0.04 mm
  • Positioning accuracy: XYZ Axis 0.01 mm
  • Printing speed: 120 mm/s
  • Traveling speed: 200 mm/s
  • Nozzle temperature: Max. 400 deg
  • Hot bed temperature: Max. 120 Degree
  • Filament materials: PLA, ABS, PVA
  • Filament diameter: 3.0 mm (1.75 mm optional)
  • OS platform: Windows, Linux, Mac OS, OSX
  • Language: English, Multi-language
  • Software: CreatBot multi-language version
  • File format: STL, OBJ, GCode, Amf
  • Control chip: ATmega 2560
  • LCD Size: 128*64 monochrome multi-language
  • Power supply: 110~220V 360W
  • Machine dimensions weight:
  • 370*420*530mm 25Kg
  • Packaging dimensions weight:
    1. 460*490*620mm 28Kg DM Mini
    2. 510*560*670mm 39Kg DM
    3. 510*560*820mm 47Kg DM Plus

CreatBot Featured

All Metal Chassis

The 3D printer requires a certain weight to insure the stable operation, so a mental chassis is the best choice for a 3D printer. All the CreatBot 3D printers use the unified rugged metal chassis, the usage of the unique one-piece solid process can insure the printer is strong and precise. It ensures the chassis does not deform in a very long-distance transportation to you.

Smart Adjustable Extruder

CreatBot extruders have an intelligent cooling system, this keeps the filament feeding at the optimal tempeature. The height-adjustable-nozzles design allows you to align multiple nozzles more quickly and easily, this insures the perfect coordination when you print your multi-color models. CreatBot supports up to three heads.

Geared Motors Feeder

Geared motors can produce more torque compared to the general stepper motor, this can ensure the filament does not slip while wire feeding, ensuring the feeding precision and retraction. The design of wire feed roller also ensure the wire feeding does not damage filament.

Ceramic Hot Bed Panel

Ceramic hot bed panel with unidirectional thermal characteristics makes the heating area uniform, the thermal efficiency is greatly improved as well as energy-saving. The ceramic panel has a smooth look and more high-end appearance. Silicone based ceramic heating panels also have a very long life.

Metal Hot Bed Tray

A metal hot bed tray has greater rigidity, which ensures less vibrations while working. The metal bracket for fixing hot bed tray has a thickness up to 10mm, making the whole hot bed and body design blend into one harmonious and very strong printer.

Remote Wire Feeder Architecture

The characteristic of remote wire feeder architecture is such that the wire feeding device is not on the head, ensuring the lightest possible extrusion head. Lower inertia allows for maximum speeds during printing.

*The purchaser is responsible for any taxes and duties payable on entry to the country before delivery can be completed.*
