CREATBOT D600 AND D600 PRO HIGH TEMP LARGE FORMAT PRINTING AT ITS BEST!!

CREATBOT

$13,899.00

MODEL
Quantity

THE D600 AND D600 PRO ARE CREATBOTS TOP OF THE RANGE MODELS.

LARGE FORMAT PRINTERS WITH THE CAPABILITY OF PRINTING MATERIAL REQUIRING HIGH TEMPS UP TO 420DEG.

CLICK HERE TO VIEW CREATBOTS D600 PRO PRESENTATION WITH VIDEOS OF THESE AMAZING PRINTERS IN ACTION.

Temperature Up to 400°C

We are the first manufacturer to introduce a 400°C ultra-hight temperature nozzle to the market . This kind of nozzle allows you to print with a variety of filaments. And the blue metal cooling sink can efficiently cool down the heatbreak. the nozzle height can also be micro adjusted.
CreatBot D600 All Metal HeadMetal Hotend Icon All metal hotend, more durable

400°C Hotend Icon 400°C support more supplies


Nozzle Height Adjustable Icon Nozzle height adjustable

Three Nozzle Icon Direct Head Driving

High Precision

We exclusively researched and developed the extruder feeding system which supports high-speed printing, and accuracy it can reach as high as 0.05mm, it allows extrusion of filament steadily with out blockage.
Precision up to:
0.01mm Speed up to: 200mm/s

CreatBot D600 High Precision Sample

Stability

The steel body not only ensures stability when printing but greatly extends the usage period. the optimization and cooperation of the overall structure ensures sustainable and efficient operation. The first batch of CreatBot 3D printers have been working for 5 years and more than 8000 hours.
CreatBot D600 All Metal Chassis

Huge Build Volume

D600 is a real industrial level 3D printer, it can print largest build volume of 600*600*600mm, 30 times bigger than the ordinary 3D printer on the market.

CreatBot D600 build volume:
600*600*600mm
CreatBot D600 Large Build Size Printer

Fully Enclosed Chamber

The fully enclosed chamber can block all external interference. Also this frame can reduce noises, at the same time to provide constant temperature, so that the model won't deform.
CreatBot D00 Fully Enclosed Chamber

Accurate Linear Guide Rail

The accurate linear rail structure can print models in accuracy high reach to 50 times higher than the other ordinary optical axis printers on the market. This structure offers accurate filament feeding, so that can print large model fast and precisely.


CreatBot D600 Linear Guide Rail

Outage Restored & Filament Detection

The printer will automatically memorize the current position and save the print data, lower the working platform and withdraw filament when the power turns off suddenly.

CreatBot D600 Filament Detection

Efficient Platform

The platform surface is attached with the 3D printing special stickers, and the printer has vertical thermal conductivity so that can support high thermal efficiency. You can set the parameters to turn off the hot bed automatically after the specified number of layers.
CreatBot D600 Efficient Platform

Easy Touch Screen

The printer has a 4.3" touch screen, very easy to operate. We also provide One-Key to preheat, print, home as well as other shortcut keys.
CreatBot D600 Touch ScreenCreatBot Pla Filament

Technical Specs

CreatBot D600

Printing

Print Technolody:

Fused Deposition Modeling

Build Volume:

600*600*600mm

Number of Nozzles:

Double

Resolution:

0.01mm

Layer Resolution:

0.05mm

Filament Diameter:

3.0mm (1.75mm optional)

Filament Compatibility:

PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PTEG, HIPS, PP, Flexible, TPU, PVA, etc.

Nozzle Diameter:

0.4mm (0.3, 0.5, 0.6, 0.8, 1.0mm)

Print File Type:

GCO, GCODE

Temperature

Ambient Operating Temperature:

15-32°C

Max. Nozzle Temperature:

400°C

Max. Bed Temperature:

100°C

Speed

Best Printing speed:

45mm/s

Max. Printing speed:

120mm/s

Max. traveling speed:

200mm/s

Mechanical

Construction:

Powder-Coated Steel, Aluminum Casting for Motion Components, POM

Build Plate:

Microcrystalline Ceramic Panel

Build Plate Leveling:

Factory Leveled, Adjust Manually

Extruder:

Geared motor (1:10 rate)

Stepper Motors:

1.8° Step Angle with 1/16 Micro-stepping

X Y Positioning Precision:

5.08 Microns

Z Positioning Precision:

1.25 Microns

Electrical

Power Requirements:

100-240V, 50-60Hz

Max. Power:

1000W

Screen:

4.3" Touch Screen with Multi-language

Control Chip:

ATmega 2560

Storage Media:

SD Card

Connectivity:

USB

Software

Software Bundle:

CreatWare Multi-language

Supported File Types:

STL, OBJ, AMF

Operating Systems:

Windows (7,8,10)




Mac OS X

Special Function

Outage Restored:

Sava data when power is off

Filament Detection:

Pause printing when filament run out

Automatic Shut-down:

Turn off the power automatically when printing is complete

Size & Weight

Product Dimensions & Weight:

915*845*1085mm 125Kg

Packing Size & Weight:

1000*1030*1360mm 190Kg (Pallet)

*Taxes and duties payable on entry to the country are to be paid by the purchaser*

SKU: 10056
