Wanhao Duplicator 4S

The Duplicator 4S is the latest update to our Duplicator 4 series of printers. This printer comes with all of the great features of the Duplicator 4X (hinged safety door, two side safety panels, and a detachable hood) but has also been updated to include a steel exoframe, a steel printing platform, and a larger Z-Axis threaded rod. Other features include upgraded electronics and 1/16 micro-stepping motor control.This printer takes the Duplicator 4 to the next level!

This model is recommended for Schools, Home Workshops, and Office Tinkerers.




Features:

• Extruder: New! MK10 Dual-Extruders
• Filament Size: 1.75mm Dedicated
• Layer Capability: 0.1mm - 0.5mm
• Build Envelope: 225mm x 145mm x 150mm
• Filament Capabilities: ABS, PLA, PVA
• Compatible Software/Firmware: ReplicatorG (Opensource), Sailfish (Opensource), Simplify 3D
• Warranty: 1 Year Limited Factory Warranty
• Frame Color: Black Steel Exoframe

Mechanical Property:

Overall dimensions: 320 x 466 x 382 mm | 12.6 x 18.4 x 15 in.
Shipping Weight: 25kg.
Linear ball bearings.
Precision ground 8mm shafts.
Snap-on, snap-off carriage assemblies.
Electronics Property:

Duplicator 4S.
single-piece motherboard.
5 axis, 1/16 micro-stepping motor control.
4x20 LCD character display and multi-direction control pad.
Piezoelectric buzzer.
DOUBLE Power Supply: 110 AND 250V, 50/60Hz, 4.0A (input), and takes standard IEC cable.
Software: Replicator G/ Simplify 3D(Optional)

Compatibility: Linux, OSX, and Windows.
Print from SD card or over USB.
Input file type: STL, gcode.
Overview Features Specifications:

Build envelope 225 x 145 x 150 mm | 8.9 x 5.7 x 5.9 in.
Build volume About 5 liters.
Layer thickness Choose 0.1-0.5 mm which is adjustable by software.
Stock nozzle diameter Stock 0.4 mm.
Speed 40 mm/s.
Flow Rate Approximately 24 cc/hr.
Extruder Temperature Recommended Maximum 230 C.
Heated Build Platform 120 C Maximum.
Positioning precision 2.5 micron on Z axis.
11 micron on XY axis.
Printing Materials:

Works with ABS, PLA and other materials.
Filament diameter: 1.75 mm.
