CREATBOT F430, 420DEG hot end, dual extruder.

Support 400°C Hot end

We are the first manufacturer to produce a 400°C high temperature nozzle for the 3d printer market. F430 is equipped with dual extruders. allowing you to print with a variety of filaments. The nozzles height can also be micro adjusted.

400°C Hot end

Direct Drive

High Precision & High Speed

We exclusively researched and develop the extruder feeding system, which supports high-speed printing. Its printing accuracy can reach as high as 0.04mm allows extrusion of filament steady without blockage.
Precision up to:
0.04 mm
Speed up to:
120 mm/s

High Precision

Stability

The body is completely steel construction not only ensuring stability when printing, but also extends the usage period greatly. Ensuring a sustainable and efficient operation. The first batch of CreatBot 3D printers have been working for 5 years and more than 8000 hours.

Metal Chassis

Fully Enclosed High-Temperature Chamber

Fully enclosed chamber can shield all external interference and reduce noise. Hot chamber can provide constant build space temperature so that your models won't deform when printing.


Fully Enclosed Hot Air System

Outage Restored & Filament Detection

The printer will automatically memorize the current position and save print data. Lower the platform and withdraw filament when power is turned off suddenly. It will continue print from where it stopped after the power is turned back on.
The printer will avoid invalid printing by stoping print and warning when filament runs out.
Outage Restored

Filament Detection

Touch Screen

The printer has an all-English-menu touch screen, easy operation and friendly use. One key to warm, one key to print as well as many other shortcut keys.

Touch Screen

Efficiently Platform & 130°C Hotbed

The hotbed is made of heatable aluminium PCB, which can be heat up to 130°C fast. The platform comes with 3d printing adhesive build tack mats.

Carbon Fiber Platform

Removable Panel

The hotbed is attached with a carbon fiber panel, which allows for fast transfer of heat. The carbon fiber panel is removable, and you can bend panel to help release the printed object.

Removable Panel

Air Filter System

The air filter system can adsorb impurities and gases that are generated by printing special filament, a must if you are printing in doors.

Air Filter System

Technical Specs

CreatBot F160

Printing

Print Technolody:

Fused Deposition Modeling

Build Volume:

400*300*300mm (F430)

Number of Nozzles:

Double

Resolution:

0.04mm

Layer Resolution:

0.02mm

Filament Diameter:

1.75mm

Filament Compatibility:

PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PTEG, HIPS, PP, Flexible, TPU, PVA, PEEK, etc.

Nozzle Diameter:

0.4mm (0.3, 0.5, 0.6, 0.8, 1.0mm)

Print File Type:

GCO, GCODE

Temperature

Ambient Operating Temperature:

15-32°C

Max. Nozzle Temperature:

400°C

Max. Bed Temperature:

130°C

Max. Cabinet Temperature:

70°C

Speed

Best Printing speed:

55mm/s

Max. Printing speed:

180mm/s

Max. traveling speed:

200mm/s

Mechanical

Construction:

Power-Coated Steel, Aluminum Casting for Motion Components, POM

Build Plate:

Heatable Aluminium PCB with BuildTak

Build Plate Leveling:

Automatic

Extruder:

Directly Drive

Stepper Motors:

1.8° Step Angle with 1/16 Micro-stepping

X Y Positioning Precision:

12.7 Microns

Z Positioning Precision:

1.25 Microns

Electrical

Power Requirements:

100-240V, 50-60Hz

Max. Power:

300W

Screen:

4.3" Touch Screen

Control Chip:

ATmega 2560

Storage Media:

USB Disk

Connectivity:

USB

Software

Software Bundle:

CreatWare Multi-language

Supported File Types:

STL, OBJ, AMF

Operating Systems:

Windows (7,8,10)
Mac OS X

Special Function

Outage Restored:

Sava data when power is off

Filament Detection:

Pause printing when filament run out

Automatic Shut-down:

Turn off the power automatically when printing is complete

Size & Weight

Product Dimensions & Weight:

660*470*580mm 43Kg

Packing Size & Weight:

760*620*680mm 58Kg

ALL ORDERS FOR THIS PRINTER ARE BEING SHIPPED FROM THE CREATBOT FACTORY IN CHINA
