WANHAO D9 MK2, 300 deg extruder,All metal hotend!

The Wanhao Duplicator 9 Mark 2 is a large format 3D Printer.

 Wanhao haven't just scaled up a current i3 style printer with the D9, it combines proven technology from various manufacturers and utilizes the best parts of the competition in to a large format, FDM Cartesian Style Monster.

With an all metal hot end, materials like PLA,PVA, Nylon, ABS, and even polycarbonate are printable. The 300C capabilities of the hot end. 2020 extruded aluminum precision frame, guide rails, and v-slot bearing design,  all working with the large 300 X 300 build platform give the user the ability to create large precision prints., The easy to use intuitive touch screen control system making controlling your printer a breeze.  Additionally the added resume after power failure, and internally mounted power supply and control systems keeps the footprint of the machine as compact as possible while adding a feature rich experience straight out of the box.

Technical Specifications

Primary attributes of the technology

PLA printer, Entry level printer, Fully assembled, Developed from Prusa i3.

Software

Cura, Host by Repitator, Simplify 3D.

Extruder System

MK10 extruder with full metal hot end.

Material Support

PLA, PVA, PEVA, ABS, Nylon. Any material melting point greater than 300 Degrees Celsius will be supported.

Max Printable Area

300 x 300 x 400mm / 400 x 400 x 400mm / 500 x 500 x 500mm

Filament Diameter/Light

1.75mm

Max Printing Speed

70mm per second

Case Material

Aluminum Case

Insulated cover

Insulated Cover Available

Extruder Quantity

1

Accuracy

X Axis: 0.012mm

Y Axis: 0.012mm

Z Axis: 0.004mm

Net Weight 44 LB

Gross Weight 48.5 LB

Auto Bed Leveling

Packing Size (cm)

60 x 50 x 35

Platform Holder

Steel Frame Holder

Rail Locking System

Steel Bolt Locking Frame

Layer Thickness

100 micron - 400 micron

Platform; Aluminium Platform With Heating

Resume Printing

Can Resume Printing After Power Break.

LCD Disply

Customize Any Language

Power Supply Unit; Inside 110 & 250V (optional)

50/60Hz

4.0A (input) and takes standard IEC cable.

Typical Application

A perfect printer for technical educators and a great printer for DIY hobbyist.

Currently being shipped directly from the Wanhao factory in China. Any tax or duties payable on entry to the country are the buyers responsibility.
