CREATBOT DE SERIES
- Product name: CreatBot DE Series
- Build size (LDH):
- 400*300*300mm DE
- 400*300*520mm DE Plus
- Single/double head dual color model build width 380mm
- Tris head mono color model build width 380mm
- Tris head two color model build width 360mm
- Tris head three color model build width 340mm
- Number of nozzles: single / double / Tris
- Nozzle diameter: 0.3, 0.4, 0.5, 0.8, 1.0mm
- Minimum thickness: 0.04 mm
- Positioning accuracy: XYZ Axis 0.01 mm
- Printing speed: 120 mm/s
- Traveling speed: 200 mm/s
- Nozzle temperature: Max. 250 Degree (400 degreee opt.)
- Hot bed temperature: Max. 120 Degree
- Filament materials: PLA, ABS, PVA
- Filament diameter: 3.0 mm (1.75 mm optional)
- OS platform: Windows, Linux, Mac OS, OSX
- Language: English, Multi-language
- Software: CreatBot multi-language version
- File format: STL, OBJ, GCode, Amf
- Control chip: ATmega 2560
- LCD Size: 128*64 monochrome multi-language
- Power supply: 110~220V 360W
- Machine dimensions weight:
- 590*430*560mm 45Kg DE
- 590*430*780mm 55Kg DE Plus
- Packaging dimensions weight:
- 730*570*700mm 60Kg DE
- 730*570*920mm 80Kg DE Plus
All Metal Chassis
The 3D printer requires a certain weight to insure the stable operation, so a mental chassis is the best choice for a 3D printer. All the CreatBot 3D printers use the unified rugged metal chassis, the usage of the unique one-piece solid process can insure the printer is strong and precise. It ensures the chassis does not deform in a very long-distance transportation to you.
Smart Adjustable Extruder
CreatBot extruders have an intelligent cooling system, this keeps the filament feeding at the optimal tempeature. The height-adjustable-nozzles design allows you to align multiple nozzles more quickly and easily, this insures the perfect coordination when you print your multi-color models. CreatBot supports up to three heads.
Automatic System Shutdown
CreatBot's DX/DE latest 3D printer is equipped with a power management module, supporting automatic shutdown after printing. When the printing has completed and there is no keyboard action within five minutes, the system will automatically turn off the printer. This feature is very useful, as well as being very energy efficient.
Exclusive Multi-function Keypad
CreatBot's DX/DE is the latest 3D printer equipped with a multi-function keyboard, supporting ONE-CLICK direct access to a certain function. The keyboard has 9 shortcut keys, each key has different functions in different situations. Supporting features include: Z shaft to move up and down, heating or cooling hot bed, suspend or resume printing, one click browse SD card, one click back to the main interface and other unique programmable functions.
Geared Motors Feeder
Geared motors can produce more torque compared to the general stepper motor, this can ensure the filament does not slip while wire feeding, ensuring the feeding precision and retraction. The design of wire feed roller also ensure the wire feeding does not damage filament.
Ceramic Hot Bed Panel
Ceramic hot bed panel with unidirectional thermal characteristics makes the heating area uniform, the thermal efficiency is greatly improved as well as energy-saving. The ceramic panel has a smooth look and more high-end appearance. Silicone based ceramic heating panels also have a very long life.
Metal Hot Bed Tray
A metal hot bed tray has greater rigidity, which ensures less vibrations while working. The metal bracket for fixing hot bed tray has a thickness up to 10mm, making the whole hot bed and body design blend into one harmonious and very strong printer.
Remote Wire Feeder Architecture
The characteristic of remote wire feeder architecture is such that the wire feeding device is not on the head, ensuring the lightest possible extrusion head. Lower inertia allows for maximum speeds during printing.
