CREATBOT PEEK 300 PRINTER

CREATBOT

$17,750.00

Quantity


Features of the PEEK 300.

Heat control system
High temp. hotend
hotbed
hot chamber

Direct Annealing System
Cooling system
liquid cooling
Air pump cooling

参数配置图标The things that make the PEEK 300 stand out.

Hotend max. 500°C with dual extruder
Heatbed max.200°C
Hot chamber max. 120°C
Build volume: 300 x 300 x 400 mm
Triple heat isolation and liquid cooling system

专利技术图标DIRECT ANNEALING SYSTEM.

The Direct Annealing System (DAS) is a revolutionary technology designed and patent protected by CreatBot. It is the most advanced technology applied to 3D printing of high performance material.

性能材料图标The PEEK 300 is capable of printing;

Engineering Plastics: PLA, PC, ABS, PA6, PETG, PVDF, POM-C, PP, TPU
High temperature Material: PPSU, PEI (ULTEM), PA12, PSU, PPS, PA-CF
Ultra performance material: Medical grade PEEK, PEEK, PEKK, CF-PEEK (Carbon fiber), GF-PEEK (glass fiber), etc

Direct Annealing Temperature: 0-400°C
Direct Annealing System (DAS), the world's first and extraordinary technology by CreatBot. Annealing process is  controllable during printing. It aims to provide best quality parts straight from the printing bed without warping and cracking printing of big size functional models. (The technology is patent protected and available from CreatBot only)

Before annealing
Before Annealing

After annealing
After Annealing

Smart Auto-rising dual extruders 500 ℃

The PEEK-300 is equiped with CreatBot's new technology smart Auto-rising dual extruders. Water cooling, DAS system, Auto-rising extruders. The dual nozzle temperature up to 500°C means you can print any 3D printing materials available in the world today.

Hotbed
Hotbed 200 ℃

An essential requirement of printing big models with no warping.

Hot Chamber

Hot Chamber 120°C

Prevents warping and cracking.

Triple Heat insulation

Triple heat insulation is made of double insulation chamber, advanced insulation materials and vacuum double PC boards. For high performance and safety.



Cooling System

The cooling system is one of the most important parts to constitute the whole thermal system. It is made of(1) liquid cooling. Circulating liquid can be used effectively for a long time.(2) Air pump cooling. Air pump provide cold air from outside instead of hot air inside chamber.

HEPA Air Filtration

The air filter system can adsorb impurities and gases that are generated by printing special filament, safe and better for the environment.

CreatBot peek-300 feature picture

0.04mm is an available resolution for normal plastics, but it is an extraordinary resolution for high warping and high deformation materials. 3D printing high performance material requires high temperature, but also better cooling. For high resolution with small detail, high temperature will ruin layers if heat and cooling are not in a balance.

Product Parameter

Printing
Build Volume
300*300*400mm
precision
0.04mm-0.4mm
Filament Diameter
1.75mm
Number of Nozzles
Dual Extruder
Print Speed
10-150mm/s
Nozzle Diameter
0.4mm (0.3~1.0mm optional)
Filament Compatibility
Engineering Plastics: PLA, TPU, PC, ABS, PA6, PETG, PVDF, TPUHigh temperature Material: PPSU, PEI (ULTEM), PA12, PSU, PPS, PA-CF, POM, PPUltra-performance material: Medical grade PEEK, PEEK, PEKK, CF-PEEK (Carbon fiber), GF-PEEK (glass fiber), etc.
Software
Software Bundle
Creatware, Simplify3D, Cura, Slice3r
Operating Systems
Win7/8/10
Print File Type
STL, OBJ, AMF, Gcode
Special Function
Outage Restored
Save data when power is off
Filament Detection
Pause printing when filament run out
Direct Annealing System (DAS)
Annealing process is controllable during printing. It aims to provide best quality parts without warping and cracking printing of big size functional models.
Heat insulation
Triple heat insulation
Emergency stop switch
Support emergency stop
High temperature accessories
High temperature resistance motors, linear rails, belts and circuits to ensure long time high temperature printing.

Temperature
Nozzle Max. Temperature
500℃
Chamber Temperature
120℃
Platform Max. Temperature
200℃
Direct Annealing Temperature
0~400℃
Mechanical
Cooling
Air pump cooling & water cooling
Platform
PCB aluminum + PEEK print board
Positioning Precision
X Y axis 0.0127mm, Z axis 0.00125mm
Extruder
Directly Drive
Machine Construction
Fully enclosed hot chamber
Bed Leveling
Manually/Automatic
Electrical
Input Power
200V~240V, 20A
Rated Power
4600W
Screen
4.3'' full color touch screen, multi-language
Print Method
USB Connectivity/USB Disk
Size & Weight
Machine Size
650*600*750 mm
G.W
100 kg
Packing Size
820*720*1080mm
N.W
130 kg





SKU: 10000-33
